Properties

• Torques: 113 – 26403 Nm
• Shaft diameter: 24 – 175 mm
• Self-centering
• Transmission of high torques

Material:
Stainless steel
Tolerance:
from 24 mm to 30 mm H6/j6
from 30 mm to 50 mm H6/h6
from 50 mm to 80 mm H6/g6
from 80 mm to 300 mm H7/g6
Surface roughness:
Rt max. 3,2 μm
